Home
Our ERVs
DN
DOAS Series
DN
3RT Packaged Refrigeration
DN
3RT Packaged Refrigeration
Application Type:
Rooftop
Ventilation Type:
Static plate, heat and humidity transfer
Typical Airflow Range:
750–3,300 CFM
AHRI 1060 Certified Core:
Three L125-G5
OA Filter(s):
Total Qty. 3, MERV 8: 20" x 20" x 2"
RA Filter(s):
Total Qty. 3, MERV 8: 20" x 20" x 2"
Weight:
1" Cabinets—3,400–4,900 lbs.; 2" Cabinets—3,525–5,100 lbs.
Find a Representative
RenewAire DN Series DOAS System | DN2RT with Packaged Refrigeration and Energy Recovery
Previous
Next
FEATURES & OPTIONS
ACCESSORIES
SUBMITTAL(S) & DRAWINGS
SPECS
LITERATURE
MANUALS
Orientation
F
H
R
V
Electrical Service
[33] 208V / 3 Phase / 60 Hz
[35] 230V / 3 Phase / 60 Hz
[34] 460V / 3 Phase / 60 Hz
[38] 575V / 3 Phase / 60 Hz
Fan Control
[E] ECM
[V] VFD
SA Fan Location
[B] Before Coil, Blow-thru (Standard)
[A] After Coil, Draw-thru
Vibration Isolation
[N] Neoprene Isolators (Standard)
[S] Spring Isolators
Controls
BACnet Factory Activation Available
GFCI Convenience Outlet
Available
Recirculation Damper
Available
Cooling
[D] Direct Expansion Coil
[R] Direct Expansion & Hot Gas Reheat Coils
Heating
[-] None
[E] Electric Heater
[G] Gas Heat Module
[S] Steam Coil
[H] Hot Water Coil
Packaged Refrigeration
[P] Packaged Refrigeration
Insulation
[1] 1" Insulation (Standard)
[2] 2" Insulation
Paint
2500 Hour Salt Spray
None (Standard)
Drain Overflow Switch
Available
Mist Eliminator
Available
Controls
Occupancy Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131302
Ceiling Mount, MC-C
Occupancy Sensor Manual (PDF)
|
PDF (1MB)
Occupancy Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131303
Wall Mount, MC-W
Occupancy Sensor Manual (PDF)
|
PDF (1MB)
CO2 Sensor, SL, EV Premium, HE, LE, RD, DN, P/N 131304
Wall Mount, CO2-W
CO2 Accessory Control Manual (PDF)
|
PDF (1MB)
CO2 Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131305
Duct Mount, CO2-D
CO2 Accessory Control Manual (PDF)
|
PDF (1MB)
IAQ Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131307
Duct Mount, IAQ-D
IAQ Wiring Supplement (PDF)
|
PDF (1MB)
IAQ Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131308
Wall Mount, IAQ-W
IAQ Wiring Supplement (PDF)
|
PDF (1MB)
Room Temperature and Humidity Sensor, DN, P/N 102397
Wall Mount, RTH-W
Smoke Detector, HE, LE, RD, DN, P/N 102396
Duct Mount, SD-D
Remote Display, HE, LE, RD, DN, P/N 131311
Units with Enhanced or Premium Controls, Handheld/Wall Mount RD-M
Room Pressure Sensor, HE, LE, RD, DN, P/N 131314
Sensor with Display, Units with Premium Controls, RPS-WD
Room Pressure Sensor, HE, LE, RD, DN, P/N 131310
Sensor without Display, Units with Premium Controls, RPS-WOD
Duct Static Pressure Sensor, HE, LE, RD, DN, P/N 131315
Sensor with Display, Units with Premium Controls, DPS-WD
Duct Static Pressure Sensor, HE, LE, RD, DN, P/N 131309
Sensor without Display, Units with Premium Controls, DPS-WOD
Temperature Sensor Kit, HE, LE, RD, DN, P/N 131318
Units with Premium Controls for non-integrated heating, TS
Roof Curbs
Roof Curb, DN-3RT, P/N 109173
Standard 14", ERV + Cooling
Roof Curb, DN-3RT, P/N 109172
Standard 14”, ERV + Cooling + Heating
Curb Clip Kits
Curb Clip Kit, DN-3RT, P/N 109165
ERV + Cooling or Heating, 1" Cabinet
Curb Clip Kit, DN-3RT, P/N 109164
ERV + Cooling + Heating, 1" Cabinet
Curb Clip Kit, DN-3RT, P/N 168104
ERV + Cooling or Heating, 2" Cabinet
Curb Clip Kit, DN-3RT, P/N 168103
ERV + Cooling + Heating, 2" Cabinet
Filters
Filter, DN-3, P/N 990686
MERV 13 20"x20"x4" Single Filter
Filter, DN-3, P/N 990688
MERV 14 20"x20"x2" Single Filter
Filter, DN-3, P/N 990690
MERV 14 20"x20"x4" Single Filter
Filter, DN-3RT, P/N 990681 24"x28"x3/8", Filter for Mist Eliminator Option
Filter, HE, CA, PA, RD, DN-3, P/N 990083
MERV 8 20"x20"x2" Single Filter
Filter, HE, CA, PA, RD, DN-3, P/N 990303
MERV 13 20"x20"x2" Single Filter
Coil Accessories
Waterless Trap, DN, P/N 102387
Positive Pressure, WT-P
Waterless Trap, DN, P/N 102386
Negative Pressure, WT-N
DN3RT Packaged Refrigeration Standard
DN3RT Packaged Refrigeration Submittal (PDF)
pdf (2MB)
DN3-JRT PKGD ERV+COIL 1" Dimension Drawing (PDF)
pdf (212KB)
DN3-JRT PKGD ERV+COIL 1" Dimension Drawing (DWG)
dwg (3MB)
DN3-JRT PKGD ERV+COIL 1" Revit (BIM)
rfa (548KB)
DN3-JRT PKGD ERV+COIL+HEAT 1" Dimension Drawing (PDF)
pdf (208KB)
DN3-JRT PKGD ERV+COIL+HEAT 1" Dimension Drawing (DWG)
dwg (2MB)
DN3-JRT PKGD ERV+COIL+HEAT 1" Revit (BIM)
rfa (548KB)
DN3-JRT PKGD ERV+COIL 2" Dimension Drawing (PDF)
pdf (221KB)
DN3-JRT PKGD ERV+COIL 2" Dimension Drawing (DWG)
dwg (2MB)
DN3-JRT PKGD ERV+COIL 2" Revit (BIM)
rfa (544KB)
DN3-JRT PKGD ERV+COIL+HEAT 2" Dimension Drawing (PDF)
pdf (253KB)
DN3-JRT PKGD ERV+COIL+HEAT 2" Dimension Drawing (DWG)
dwg (3MB)
DN3-JRT PKGD ERV+COIL+HEAT 2" Revit (BIM)
rfa (564KB)
DN3-JRT ERV+COIL Curb Dimension Drawing (PDF)
pdf (58KB)
DN3-JRT ERV+COIL Curb Dimension Drawing (DWG)
dwg (761KB)
DN3-JRT ERV+COIL+HEAT Curb Dimension Drawing (PDF)
pdf (59KB)
DN3-JRT ERV+COIL+HEAT Curb Dimension Drawing (DWG)
dwg (331KB)
DN Refrigeration P&ID Schematic 1-Circuit (PDF)
pdf (47KB)
DN Refrigeration P&ID Schematic 1-Circuit HGRH (PDF)
pdf (52KB)
DN Refrigeration P&ID Schematic 2-Circuit (PDF)
pdf (90KB)
DN Refrigeration P&ID Schematic 2-Circuit HGRH (PDF)
pdf (95KB)
DN Series CSI
DN-CSI-DOC
|
PDF (456KB)
DN-CSI-DOC
|
File (311KB)
DN Series Dedicated Outdoor Air System Catalog
pdf (18MB)
RenewAire ERV Guide Brochure
pdf (3MB)
DN Series Brochure
pdf (6MB)
Dedicated outdoor air units with energy recovery
DN Series DOAS with Integrated Refrigeration & Energy Recovery Brochure
pdf (909KB)
For Outdoor Applications
WELL Building Standard, IAQ and ERVs Flyer
pdf (460KB)
RenewAire ERV Guide Flyer
pdf (998KB)
DN Series Packaged Refrigeration Supplement (PDF)
pdf (5MB)
DN Series Rooftop IOM (PDF)
pdf (10MB)
DN Series Start-up Guide (PDF)
pdf (4MB)
Curb Clip Manual DN (PDF)
pdf (1MB)
DN Series Controls User Guide (PDF)
pdf (18MB)
DN Series Electric Heater User Guide (PDF)
pdf (2MB)
DN Series Gas Heat Module User Guide (PDF)
pdf (8MB)
DN Series Rigging User Guide (PDF)
pdf (4MB)
