Application Type:Indoor
Ventilation Type:Static plate, heat and humidity transfer
Typical Airflow Range:150-300 CFM
OA Filter(s):Total Qty: 1, Merv 8: spun polyester media, 10 1/2"x 21 3/4" x 1"
RA Filter(s):Total Qty: 1, Merv 8: spun polyester media, 10 1/2"x 21 3/4" x 1"
Dimensions:33 1/4" L x 23 7/8" W x 20" H
Weight:72 lbs.
Find a Representative
Orientation

Electrical Service
120V / 1 Phase / 60 Hz
Line Cord Power Connection
EA/FA Fan Motor
Fixed Speed / ODP / PSC - Direct Drive (Standard)
Controls
Onboard 24 VAC Transformer/Relay Package with Switched Dry Contacts
Low-voltage Circuit for Controls
Cross-core Differential Pressure Ports
Filter Type
MERV 8 (Standard)
Wall
[S] Single (Standard)
Paint
White Paint
Controls
Digital Time Clock, SL, EV, EV Premium, HE, LE, RD, P/N 131300
Wall Mount, TC7D-W
Digital Time Clock Manual TC7D (PDF) | PDF (1MB)
Digital Time Clock, SL, EV, EV Premium, HE, LE, RD, P/N 131301
Exterior Enclosure, TC7D-E
Digital Time Clock Manual TC7D (PDF) | PDF (1MB)
Occupancy Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131302
Ceiling Mount, MC-C
Occupancy Sensor Manual (PDF) | PDF (1MB)
Occupancy Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131303
Wall Mount, MC-W
Occupancy Sensor Manual (PDF) | PDF (1MB)
CO2 Sensor, SL, EV Premium, HE, LE, RD, DN, P/N 131304
Wall Mount, CO2-W
CO2 Accessory Control Manual (PDF) | PDF (1MB)
CO2 Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131305
Duct Mount, CO2-D
CO2 Accessory Control Manual (PDF) | PDF (1MB)
IAQ Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131307
Duct Mount, IAQ-D
IAQ Wiring Supplement (PDF) | PDF (1MB)
IAQ Sensor, SL, EV, EV Premium, HE, LE, RD, DN, P/N 131308
Wall Mount, IAQ-W
IAQ Wiring Supplement (PDF) | PDF (1MB)
Percentage Timer Control, SL, EV90-300, EV Premium, P/N 140460
PTL
PTL Control Manual (PDF) | PDF (259KB)
Percentage Timer Control, SL, EV90-300, EV Premium, P/N 140470
With Furnace Interlock, FM
FM Control Manual (PDF) | PDF (206KB)
Push Button Point-of-Use Control, SL, EV90-300, EV Premium, P/N 140480
PBL
PBL Control Manual (PDF) | PDF (277KB)
Filters
Filter Set, SL, EV, EV Premium, BR, GR, P/N 990750
MERV 8, Single Set
Filter Set, SL, EV, EV Premium, BR, GR, P/N 990447
MERV 8, 3 Pack
Filter Set, SL, EV, EV Premium, BR, GR, P/N 990076
MERV 8, Box of 10
Filters, SL, EV, EV Premium, BR, GR, P/N 990579
MERV 8, 75 Pack
Filter, EV200, EV240, EV300, P/N 990754
MERV 13, Single Filter
Filters, EV200, EV240, EV300, P/N 990759
MERV 13, 3 Pack
Filters, EV200, EV240, EV300, P/N 990764
MERV 13, 10 Pack
Filters, EV200, EV240, EV300, P/N 990769
MERV 13, 25 Pack
Dampers
Motorized Damper (Powered by included furnace interlock), BR, SL, GR, EV, EV Premium S,M,L, P/N 145000 6", MD6-FM
Motorized Damper Submittals MD (PDF) | PDF (146KB)
Motorized Damper Supplement (PDF) | PDF (3MB)
Motorized Damper (Powered by included plugin transformer), BR, SL, GR, EV, EV Premium S,M,L, P/N 145010 6", MD6-PT
Motorized Damper Submittals MD (PDF) | PDF (146KB)
Motorized Damper Supplement (PDF) | PDF (3MB)
Backdraft Damper, BR, SL, GR, EV90-300, EV Premium, P/N 102401
8", BD8
RenewAire Hoods and Dampers | PDF (409KB)
Balancing Damper, BR, SL, GR, EV, EV Premium, HE, LE, P/N 131400
4", ABV-4
Automatic Balancing Damper IOM | PDF (831KB)
Balancing Damper, BR, SL, GR, EV, EV Premium, HE, LE, P/N 131401
5", ABV-5
Automatic Balancing Damper IOM | PDF (831KB)
Balancing Damper, BR, SL, GR, EV, EV Premium, HE, LE, P/N 131402
6", ABV-6
Automatic Balancing Damper IOM | PDF (831KB)
Louvered and Hooded Wall Vents
Concentric Vent Kit, BR, SL, GR, EV90-300, EV Premium, P/N 141178 Air volume capacity 110 CFM
Louvered Wall Vent, SL, EV200-300, EV Premium, HE05, P/N 102399
8" Taupe, VT8
RenewAire Hoods and Dampers | PDF (409KB)
Hooded Wall Vent, SL, EV200-300, EV Premium, HE05, P/N 102406
8" Galvanized, FA8-G
RenewAire Hoods and Dampers | PDF (409KB)
Hooded Wall Vent, SL, EV200-300, EV Premium, HE05, P/N 102409
8" Paintable Galvanneal, FA8-P
RenewAire Hoods and Dampers | PDF (409KB)
Louvered Wall Vent, SL, EV200-300, EV Premium, HE05, P/N 102412
8" Round Duct Connection - 12" (W) x 8" (H), VW12 X 8
Mounting
Select four isolators per unit with the proper load ratings per unit corner weights. See weight and center of gravity table in IOM.
